hot recommended airplane Stairs international trader for airport

Hot recommended airplane Stairs international trader for airport

Place of Origin:
Hubei, China (Mainland)
Model Number:
CMKT5800
Lead Time:
30 day(s) after payment received
Price
Get Latest Price
Get the latest price
Quantity Needed:
Pieces
E-mail:

Introduction

Aircraft passenger stairs, also known as boarding stairs or aircraft steps, are mobile staircases used to enable passengers to board and deboard aircraft. They are crucial for airports and airlines that operate smaller aircraft or those that use remote stands rather than jet bridges. These stairs provide a safe and convenient way for passengers to access the aircraft, especially in locations where jet bridges are not available.

Benefits
  • Safety

    • Ensure that the stairs are equipped with handrails, non-slip steps, and robust safety features to prevent accidents during boarding and deplaning.

  • Adjustability

    • Stairs should be adjustable to accommodate various aircraft heights. Powered stairs often provide easier and quicker adjustments.

  • Portability

    • Depending on your needs, consider whether manual or powered stairs are more suitable for the expected frequency of use and operational environment.

  • Durability

    • Aircraft passenger stairs need to withstand harsh weather conditions and heavy use. Look for models made from high-quality materials designed for durability.

Product Description

Name
Self Propelled Airport Mobile Passenger Stairs
Length (mm)
7850
Widht (mm)
2400
Height (mm)
3740
Wheel centre distance (front/rear) (mm)
2025/2000
Top speed (km/h)
25
Minimum ground clearance (mm)
160
Passenger ladder working height (mm)
2300~5800
Ladder Deep (mm)
290
Ladder width (mm)
1450
Ladder height (mm)
190
Maximum tilt angle of the ladder (°)
38
Temperature range (℃)
-15~45
Battery life (km)
60
Battery life km plus times (middle airports)
48+23
Quality (kg)
9750
Front axle carrying quality (kg)
5150
Back axle carrying quality (kg)
4600
Wheelbase (mm)
3200
Channel Outer Circle Diameter (mm)
17000
Event Platform Trips (mm)
0~300
Height adjustment
Up and down body telescopic
Number of steps on the upper ladder
13
Number of steps down the ladder
14
Number of steps on the tail ladder
1
On the platform deep (mm)
2950
Upper platform width (mm)
2165
Battery life km plus times (large airports)
48+22
Battery life km plus times (small airports)
49+24
Speed control controller
Input voltage (VDC)
80
Rated output voltage (VAC)
50~55
Speed-up mode
Vector speed
Battery
Type
Lead acid
End voltage (V)
80
Rated capacity Ah
640
Drive motor
Type
AC variable frequency
Rated power (kw/r/min)
23/2063
Rated current (A)
295
Insulation grade
H
Protection level
IP55
Rated voltage (VAC)
55



Which Aircraft Models are our Airport Electric Aircraft Passenger Stairs applied for?


The designed height is from 2300mm to 5800mm, which could be slightly adjusted for height tolerance between passengers stair and hatch, height of stair platform could reach 5800mm after slight adjustment, this type of passengers stair could be applied for A310, A320, A330, A340, B737, B747, B757, B767, B777 & etc.


Detailed Images


hot recommended airplane Stairs international trader for airport-1

hot recommended airplane Stairs international trader for airport-2


Detailed Image of Self Propelled Airport Electric Aircraft Passenger Stairs
Product packaging
hot recommended airplane Stairs international trader for airport-3
Packing of Self Propelled Airport Aircraft Passenger Stairs
It's packed by frame container, the freight fee is a little higher compared with standard shipping container.
Company Introduction

hot recommended airplane Stairs international trader for airport-4

hot recommended airplane Stairs international trader for airport-5


Excellent qulity & fast delivery
We are specializing in the production of Self Propelled Airport Electric Aircraft Passenger Stairs

FAQ
Q: Are you trading company or manufacturer ?
A: We are factory.

Q: How long is your delivery time for Mobile Passenger Stairs?
A: It's depend on your quantity requirement & when you make order, generally, it's 3~4 months.

Q: Do you provide sample? Warranty?
A: No, but you are welcome to visit our factory or I can show you some of our sales record.
The standard warranty is one year.

Q: What is your terms of payment for Mobile Passenger Stairs?
A: 30% T/T in advance ,balance before shippment.
Question For Fast Quotation
Q1: Do you need Mobile Passenger Stairs with Maximum load-bearing 60 peoples or 70 peoples at the same time?

Q2: How many do you need?

Q3: Need we arrange shipment for you? if yes, tell us name of discharge port.

Wecome to contact us at any time.




Cheerong airplane Stairs is designed with an aesthetically-pleasing look that sets it apart from the ordinary. Its material is antibacterial and inhibits the growth of pathogenic microorganisms
The design of Cheerong plane stairs combines aesthetics and functionality. It makes passenger's takeoff smooth and easy
Cheerong plane stairs is manufactured using state-of-the-art technology to guarantee the fine workmanship and smooth production. It helps minimize downtime and maximize operational efficiency
Cheerong plane stairs is offered keeping track with the latest technological developments. It helps minimize downtime and maximize operational efficiency
Being expertly conceived, Cheerong airplane Stairs shows an award-winning design. It can be designed with the front bumper to minimize walkway damage
The company has established a strict production management system to strictly control the purchase of raw materials and production quantity, reduce the loss rate of raw materials as much as possible, realize zero inventory backlog, and ensure the outstanding advantages of airplane Stairs in terms of price and quality.
