Aircraft Container(ULDs) | Air Cargo Containers

ULD Containers | Air Cargo Containers

CHEERONG company have designed and developed 10 types of avaition container, all of our aviation container have got TSO or PMA airworthiness Certificate from CAAC. Part of them have been passed TSO approved by FAA.

Most air freight containers are made of materials such as aluminum or polycarbonate and are equipped with a profile frame. They are designed to fit the contours of an aircraft cargo hold and meet the standards of the International Air Transport Association (IATA). Each container is assigned a unique IATA code, such as AKE, AKN, PAG and PMC, for easy identification.
AKE LD3 container is the most popular model in market now, it have gotten TSO Airworthiness Certificate from FAA, the size of LD3 container is 2007*1534*1626mm, it have 4.3CBM volume capacity with 1588KG loading capacity.

At CHEERONG, our air freight experts specialize in customizing cost-effective logistics solutions. In addition, we also assist in building ULD containers that fit your specific shipping requirements to ensure smooth transportation. Welcome to get free quote！

ULD Aircraft Freight Transport LD3 Container

Inquire

Aircraft Freight Transport LD8 Container

Inquire

LD2 LD3 LD8 Container ULD For Aircraft Freight Transport

Inquire

Aviation ALF Container For Airport Transportation Storage

Inquire

Aviation ALF Airport Transportation Storage Container with PVC curtain door

Inquire

Airport Aviation Cargo Transport ALF Container

Inquire

Aircraft Aviation AKE Cargo aluminum transport shipping containers with metal door

Inquire

Aviation AKE Container For Aircraft Baggage Transport

Inquire

Aviation Aircraft Baggage AKE LD3 Container

Inquire

Aviation Aircraft LD2 DPE Container

Inquire

Aviation Aluminium DPE Aircraft Cargo Metal Container for Transportation

Inquire

Aviation DPE Container Airplane Air Cargo

Inquire

Aviation Airport DPE LD2 Baggage Cargo Container

Inquire

Aviation Aircraft DQF LD8 Cargo Metal Container

Inquire

Aviation AKH Container For Airport Storage Cargo

Inquire

I am product title

Pieces

Name：

Content：

E-mail：

What is a ULD Container?

ULD Container, short for Unit Load Device(ULD), is a container used to load cargo in air transport. ULD can be a container or a combination of pallets and nets. Their main function is to secure cargo to prevent damage to the cargo itself or the inner wall of the aircraft due to movement during flight.

ULD comes in two different forms:
Aircarft Pallets – These are large flat base of aluminium with rims designed to lock onto cargo net lugs.
AircarftContainers – Also known as cans or pods, are closed units that can either be fully made out of aluminium or made out of a combination of aluminium, polycarbonate sheets and cargo nets. These are designed so that they fit perfectly in the circular cargo hold of the plane.

Advantages

Benefits of ULD Containers

The most important purpose of a ULD container is to secure cargo during flight. The safety of the plane and its passengers comes first every time. But ULDs also:

1. Eliminate the need for manual loading and unloading
2. Protect cargo contents so that goods arrived undamaged
3. Maximise the use of the aircraft’s cargo space
4. Allow the fast, easy transfer of cargo between planes

The global introduction of standardised containers has improved cargo handling enormously, lowering operational costs. That, in turn, helps lower freight charges and boosts trade flows.

Aircraft Freight Transport LD8 Container

COMMON ULD AIRCRAFT CONTAINER SPECIFICATIONS

When transporting temperature-sensitive goods or bulky cargo, specialized air cargo containers are essential for maintaining product integrity and optimizing space. Below are the specifications for some specialized air cargo containers that are commonly used in the industry.

LD1 Container

Length: 92 inches (2.34m) Width: 60.4 inches (1.53m) Height: 64 inches (1.62m) Compatibility for: Boeing 747, 777, or similar models, Suitable for smaller packages to odd-shaped items that can fit within its dimensions.

Aviation LD2 Container

IATA Code: DPE Dimensions: 61.5″ L x 60.4″ W x 64″ H Weight Capacity: 2,700 lbs (1,225 kg) Volume: 120 cubic feet (3.4 CBM) Compatibility: B767, 787 lower hold Features: Lower deck container, half-width with an angled side.

LD3 Container

Maximum Gross Weight: 3,500 lbs (1,558 kg) Volume Capacity: 115 cubic feet (3.26 CBM) Compatibility: Airbus A330, Boeing 777, Lockheed L1011 Temperature Control Range: –20°C to +20°C AKE contoured container is open on one side and closes with a flap. It is suited for a wide-body lower deck. Features: Ideal for transporting temperature-sensitive goods like pharmaceuticals and perishables.

Aviation LD7 Container

Length: 160 inches (4.1m) Width: 60.4 inches (1.53m) Height: 64 inches (1.62m) The ALF ULD, a full-width lower hold container, features angled ends. Its door is made of canvas and includes built-in door straps for added security and convenience.

LD8 Container

Dimensions: 3715(L)*1534(W)*1626(H)MM Maximum Gross Weight: 10,198 lbs (4,626 kg) Volume Capacity: 339 cubic feet (9.6 CBM) Compatibility: Boeing 747, 767, McDonnell Douglas MD-11 Features: Insulated container with a solid door, designed for larger temperature-sensitive shipments.

Aviation AKE Container

Length: 160 inches (4.1m) Width: 60.4 inches (1.53m) Height: 64 inches (1.62m) Compatibility for: B767, 747, 777, A300, A310, MD-11 Model The AKE ULD Container, a full-width lower hold container, features angled ends. Its door is made of canvas and includes built-in door straps for added security and convenience.
